GF SERIES

GF series

• Froth slurry  transfer  pump

• Specially  designed  impeller  with  mixing  and cutting  function

• Extra  large  suction diameter

• Suitable  for  pumping  froth-containing  slurry in  flotation  process, froth volume  coefficient  can  reach  3.0

• It  can  also  be  used  to  transport  high-concentration  slurry  in  the  underflow  of  high-efficiency  thickeners

• Single-stage  use, Hi-chromium  alloy  or  wear-resistant  and corrosion-resistant  rubber  lined

• Oil  or  grease  lubricated  bearing  assembly are optional


• Size:  50,  75,  100,  150,  200 mm

• Capacity:  20-800m3/h

• Head:  8-40m
